TIRE BEAD BREAKER

Actual air consumption 4CFM (113L/min)
Working pressure 6.2BAR
Speed 10000RPM
Air inlet 1/4"
Hose 3/8"
Opening 68mm
Stroke 80mm
Material S, Al
Weight 4.60Kg
Dimensions (LxWxH) 396x320x160mm

Professional pneumatic bead breaker specially designed for use on agricultural, ATV, small OTR, and most truck tires.

Extremely fast: saves time compared to conventional hydraulic bead breakers.

Ideal for working on the tire without removing the wheel: separates the tire bead from the rim using leverage.

Allows for wheel changes outside the workshop, performing repairs on-site.

Specifications:

· Length: 396 mm (9.05”)

· Weight: 4.6 kg (10.2 lb)

· Air inlet: 1/4” NPT

· Hose diameter: 10 mm (3/8”) I.D.

· Air pressure: 90 PSI (6.2 bar)

· Average air consumption: 4 CFM (113 l/min)

· No-load speed: 10,000 RPM

· Actuator stroke: 80 mm (3.1”)

· Jaw opening: 68 mm (2.7”)
